Shining3D FreeScan Combo
FreeScan Combo adopts metrology-grade accuracy, fine scanning and high precision from the FreeScan series, while providing an even lighter and…
Prijs exclusief btw, op aanvraag. Wij adviseren over de juiste printer-, nabewerkings- en materiaalconfiguratie voor uw toepassing, en leveren met installatie en training.
- Advies door specialist
- Installatie op locatie
- Training voor gebruikers
- Technische ondersteuning
Over dit product
FreeScan Combo adopts metrology-grade accuracy, fine scanning and high precision from the FreeScan series, while providing an even lighter and more compact design. It features 26 + 7 + 1 blue laser lines and an infrared scanning mode. Considering speed, versatility and accuracy, this high-performance 3D metrology solution can meet the needs of different scanning scenarios such as metrology-grade inspection, reverse engineering and further applications.
The FreeScan Combo can achieve a scanning speed of 1,860,000 points per second using the laser scan mode and a speed of 2,250,000 points per second utilizing infrared mode. FreeScan Combo delivers high accuracy according to VDI-VDE 2634-2 of 0,02 mm while capturing a vast amount of data per second.
This metrology-grade scanner has an ergonomic and compact design. With a size of 193 mm × 63 mm × 53 mm and a weight of 620 g, the FreeScan Combo comes as an easy-to-use and versatile scanner.
The different scanning modes include:
26 laser lines suitable for easy and large size laser scanning
7 parallel laser lines for scanning fine details
1 single laser line can obtain 3D data from narrow areas such as holes
Infrared mode can scan without markers
Specificaties
Specificaties
| Merk | Shining 3D |
| Technologie | Scannen |
Past dit bij uw toepassing?
Vertel wat het onderdeel moet doen: de belasting, de maatvoering, de serie en de doorlooptijd. Wij zeggen of dit de juiste keuze is, en anders welke wel.
